Understand Push-Pull Self-Locking Connectors in One Article

Understand Push-Pull Self-Locking Connectors in One Article

1. Working Principle Push to lock, light pull to unlock:

 Equipped with elastic claws and a self-locking mechanism, it gives a clicking sound to indicate proper insertion, ensuring not easy accidental disconnection even with one-hand blind insertion.

2. Typical Specifications - Number of cores: 1–32 cores - Current: 1.5 A – 50 A per core (depending on wire gauge and pole number) - Voltage: 600 V – 2,400 V - Temperature: -55 ℃ ~ +200 ℃ (for metal housing) - Plugging/unplugging life: ＞5,000 times

3. Protection Rating - Series B: IP50 (indoor/cabinet) - Series K: IP65 – IP68 (outdoor/water immersion) - Series F: IP68 (deep sea/military industry)

4. Application Scenarios

✈ Aerospace: satellites, flight control systems - Automotive: sensors, control modules

- Medical: monitors, laparoscopes

- Humanoid robots: joint power and signal bridging

Guangdong Corecon Precision Industry Co., Ltd. specializes in various industrial connector, push-pull self-locking connectors, new energy connectors, M series connectors , waterproof connectors, electric bicycle signal and power connector, and all kinds of wire harnesses.

 If you have any questions related to the connector industry, please contact us and we will provide you with free, one-stop professional solutions within 24 hours.
