🚦 Wire Color Code: What Do Red, Green, Yellow & White Wires Mean?

Did you know your electric vehicle (EV) hides a "rainbow" inside? 🔍 Red, green, yellow, white—these colors aren’t just for looks! They’re the secret language of your EV’s signal wires. Crack the code today, and you’ll never mix up connections during DIY repairs again!

🔴 Red Wire: The Power "Highway"
Function: Positive (+) Power Supply
- Connects to the battery’s positive terminal or controller, delivering energy to the system.
- ⚠️ Warning: Exposed or short-circuited red wires can cause fires—always disconnect power before handling!

🟢 Green Wire: The Grounding "Guardian"
Function: Negative (-) / Ground Wire**
- Links to the chassis or battery negative, stabilizing voltage and preventing leakage.
- 💡 Pro Tip: Some models use black instead of green—check your manual!

🟡 Yellow Wire: The Control "Commander"
Function: Turn Signal / Brake Light
- Often controls turn signals or brake lights—commands flow through this wire.
- ❗ Common Issue: Turn signals not working? Check for corroded yellow wire connectors first!

⚪ White Wire: The Data "Translator"
Function: Communication / Sensor Signals
- Transmits speed, battery level, and other data (e.g., between the dashboard and controller).
- 🔧 Mod Alert: Cutting this wire may "silence" your display—leave it to professionals!

🎯 Bonus: Other Color Secrets
- Blue Wire: Headlight or high-beam control
- Purple Wire: Anti-theft system signal (hidden but critical!)
- Dual-Colored Wires: E.g., red-black twisted pairs, often for high/low voltage signals

⚠️ Safety Note**: Wire colors may vary by brand—always check your vehicle’s manual before modifications!
