Factory Manufacture signal Push-Pull Connector B K Connector 2/3/4/5/6/7/9/10 Multi Pin Wire Compatible And Equivalent Connector
Product Advantages
Temperature range：-55°C ~ +200°C
Usage：Widely Used
Shell material：Brass Chrome Plated
Function：Airtight
Application：Industrial Automation，Camera，Industrial Machinery，Navigation，Communication，Medical，Mapping，Aerospace，Security，Electronic Equipment，Automotive
Product Details
|
model
|
Needle configuration
|
Shell material
|
insulator Material
|
needle core
|
wire clamp
|
variable parameter
|
|
|
B series
|
12
|
45
|
50
|
50
|
50
|
52
|
54
|
|
K series
|
34
|
45
|
50
|
50
|
50
|
53
|
54
|
|
S series
|
58
|
91
|
99
|
99
|
99
|
102
|
107
|
|
E series
|
76
|
91
|
99
|
99
|
99
|
105
|
107
|
|
L series
|
86
|
92
|
99
|
99
|
99
|
106
|
107
|
|
G series
|
111
|
112
|
112
|
110
|
113
|
112
|
113
|
|
C series
|
117
|
120
|
120
|
116
|
120
|
121
|
121
|
|
1D series
|
125
|
127
|
127
|
124
|
127
|
127
|
128
|
|
Basic Product Information
|
|
|
Gender
|
Male/Female
|
|
Coding
|
G KEY
|
|
Locking Type
|
Quick lock,Self Locking,Quick Release
|
|
Mounting Type
|
Cables Assembly,Panel mounted
|
|
Part No.
|
Self locking connector
|
|
General Infomation
|
|||
|
Ambient Temperature
|
-55℃~200℃
|
Mating Endurance
|
>5000 cycles
|
|
Insulator
|
PEEK
|
Connector Contacts
|
Brass with Gold Plated
|
|
Coupling Nut/Screw
|
Brass with Nickel Plated
|
Housing
|
Brass with Cr Plated
|
|
Seal/o-ring
|
/////
|
Insulation resistance
|
≥100MΩ
|
|
IP Rating
|
IP50-IP68 in locked condition
|
Shielding efficiency
|
at 10MHz>95dB / at 1GHz>80dB
|
|
Salt spray corrosion test
|
>144h
|
Certificate
|
UL/CE/ROHS/REACH/IP50
|
|
Characteristics
|
Parameter
|
|
Locking Type
|
Push pull self-latching type
|
|
Operation Temperature
|
-55~200°C
|
|
Max Humidity
|
up to 95% @ 60°C / 140°F
|
|
Shielding Efficiency
|
75dB (10MHz) 40dB (1GHz)
|
|
Resistance To Vibration
|
15g (10Hz~2000Hz)
|
|
Salt Spray Corrosion Test
|
96 Hr
|
|
Shock Resistance
|
100g,6ms
|
|
Endurance
|
5000 cycles
|
|
Protection Index(mated)
|
IP50-IP68
|
|
Pin Qty
|
2-32 contacts
|
|
Operation Voltage
|
110v-550v
|
|
Compatibility
|
Option
|
|
Suitable Cable OD
|
3.0~5.0 mm
|
|
Insulation Material
|
PPS
|
|
Out Shell Material
|
Chrome Plated Brass
|
|
Contact Type
|
Solder Male
|
