Revealing the Protection Levels of B Series Connectors

July 7th at 5:36pm

Revealing the Protection Levels of B Series Connectors

In electronic equipment, connectors are key components that ensure stable transmission of signals and power. B series connectors, with their diverse designs and reliable performance, are widely used in various industrial and commercial environments. However, different application scenarios have different requirements for the protection levels of connectors. So, what are the protection levels of B series connectors?

The protection levels of B series connectors usually follow the standards of the International Electrotechnical Commission (IEC), namely the IP rating. The IP rating consists of two numbers, the first indicating the dust protection level and the second indicating the water protection level. For example, a connector with an IP67 rating has a dust protection level of 6, indicating complete dust protection, and a water protection level of 7, indicating it can withstand short-term immersion in water.

Among B series connectors, common protection levels include IP44, IP55, IP65, IP67, etc. Connectors with an IP44 rating can prevent solid particles larger than 1mm in diameter from entering and can also prevent splashing water from intruding. The IP55 rating provides higher protection, preventing the accumulation of harmful dust and withstanding low-pressure water jets. Connectors with an IP65 rating can prevent the accumulation of harmful dust and withstand strong water jets. IP67-rated connectors are completely dust-proof and can withstand short-term immersion in water.

Choosing the appropriate protection level is crucial for ensuring the long-term stable operation of connectors. For example, in outdoor or humid environments, connectors with an IP65 or IP67 rating should be selected to prevent the intrusion of moisture and dust. In indoor or dry environments, connectors with an IP44 or IP55 rating may be sufficient.

In summary, B series connectors have a variety of protection levels that can meet the needs of different application scenarios. Understanding these protection levels can help us better select and use connectors, ensuring the stable operation of electronic equipment.

Guangdong Corecon Precision Industry Co., Ltd. leading brands hold >30% market share, validated by large-scale deployments. Top-tier after-sales services offer 24-hour response times, minimizing downtime risks. By leveraging these data-driven criteria, you can select connectors that ensure your new energy system operates safely, efficiently, and reliably.
